C80 Series Instruction Manual
5 Setting a Tool and a Workpiece
158
IB-1501453-C
5.5 Setting the Tool Management Data (Tool Management Screen)
Tool management data can be set and displayed on the tool management (T-Mng.) screen. These data are relevant to
which displayed on the [T-ofs] or [T-life] screen, that can be set the tool information. Thus the mutually-referenced data can
be set and displayed on this screen.
List view
Detailed display
Setup
T-Mng.
(1)
(2)
(4)
(1)
(2)
(5)
(3)
(6)
