C80 Series Instruction Manual
10 Troubleshooting
382
IB-1501453-C
10.4.3 Collecting the NC Data (Data Sampling Screen)
Sampling start/stop, sampling state display, setting the sampling parameters necessary for sampling are performed in the
data sampling screen. The NC internal data (speed output from NC to the drive unit, or feedback data from the drive unit,
etc.) can be sampled.
Also, the sampling data can be output externally on the I/O screen on the maintenance (Mainte) screen.
For the details, refer to "C80 Series Data Sampling Specification Manual (BNP-C3077-034)".
Diagn
