7 SETTINGS
7.3 Safety Communication Setting
65
7
7.3 Safety Communication Setting
Write the safety communication setting of the master station to the CPU module.
Make the following settings before configuring the safety communication setting. Check that the safety remote I/O module and
master/local module can perform cyclic transmission (the D LINK LED is lit).
Page 54 Network Configuration Settings
Page 57 Parameter Setting
1. Set the module parameter of the master station "To Use or Not to Use the Safety Communication Setting" to "Use".
[Module Parameter] [Basic Settings] [Safety Communication Setting] [To Use or Not to Use the Safety
Communication Setting]
2. Select "Detailed Setting" of the module parameter of the master station "Safety Communication Setting", and the "Safety
Communication Setting" window is displayed.
[Module Parameter] [Basic Settings] [Safety Communication Setting] [Safety Communication Setting]
To Next Page
