Mitsubishi Electric City Multi PUMY-SP125VKM User Manual

8
OCH668B
2-4. UNIT SPECIFICATIONS
(2) Method for identifying MULTI-S model
(1) Outdoor Unit
Outdoor unit <When using model 125 >
PU M Y - SP 125 Y K M - BS
Refrigerant
R410A
Indicates equivalent
to Cooling capacity
Power supply
V: Single phase
220-230-240V, 50 Hz
220 V, 60 Hz
Y: 3-phase
380-400-415V, 50 Hz
380 V, 60 Hz
Outdoor unit
model type
M-NET
control
Frequency
conversion
controller
Outdoor unit
MULTI-S
(kcal/ h)
Salt proof
type
Coolingcapacityindicatesthemaximumvalueatoperationunderthefollowingcondition.
 *Cooling Indoor :D.B.27°C/W.B.19.0°C
Outdoor : D.B. 35°C
*Heating Indoor : D.B. 20°C
  Outdoor :D.B.7°C/W.B.6°C
(3) Operating temperature range
Note: D.B.:DryBulbTemperature
 W.B.:WetBulbTemperature
Cooling Heating
W.B. 15 to 24°C
D.B. -5 to 52℃
*
1
D.B. 15 to 27℃
W.B. -20 to 15℃
Indoor-side intake air temperature
Outdoor-side intake air temperature
■ When connecting fresh air type indoor unit
air type indoor
Capacity of Fresh
Cooling Heating
Indoor-side and Outdoor-side
P80
D.B. 21 to 43:
*
2
W.B. 15.5 to 35:
intake air temperature
P140
D.B. 21 to 43:
*
2
W.B. 15.5 to 35:
D.B. -10 to 20℃
*
3
D.B. -5 to 20℃*
3
*
1
Thermo-OFF (FAN-mode) automatically starts if the outdoor temp. is lower than 21:D.B..
Outdoor unit
PUMY-SP112VKM.TH(-BS)
PUMY-SP112YKM.TH(-BS)
PUMY-SP112VKMR1.TH(-BS)
PUMY-SP112YKMR1.TH(-BS)
PUMY-SP125VKM.TH(-BS)
PUMY-SP125YKM.TH(-BS)
PUMY-SP125VKMR1.TH(-BS)
PUMY-SP125YKMR1.TH(-BS)
PUMY-SP140VKM.TH(-BS)
PUMY-SP140YKM.TH(-BS)
PUMY-SP140VKMR1.TH(-BS)
PUMY-SP140YKMR1.TH(-BS)
Capacity
Cooling(kW) 12.5 14.0 15.5
Heating(kW) 14.0 16.0 16.5
Compressor(kW) 3.1 3.5 3.7
*1 10 to 52°C D.B. °C:WhenconnectingPKFY-P15/20/25VBM,PFFY-P20/25/32VKM,PFFY-P20/25/32VLE(R)M,PEFY-P25/32/40VMA3-E,
Mseries,Sseries,andPseriestypeindoorunitwithbranchbox,Mseriestypeindoorunitwithconnectionkit.
*2Thermo-OFF(FAN-mode)automaticallystartsiftheoutdoortemp.islowerthan21°C D.B.
*3Thermo-OFF(FAN-mode)automaticallystartsiftheoutdoortemp.islowerthan20°C D.B.

Mitsubishi Electric City Multi PUMY-SP125VKM Specifications

General

Series	City Multi
Outdoor Unit Model	PUMY-SP125VKM
Cooling Capacity	12.5 kW
Heating Capacity	14.0 kW
Refrigerant	R410A
Operating Temperature (Cooling)	-5 to 46 °C
Indoor Unit Compatibility	Compatible with various City Multi indoor units
Power Supply	380-415V, 50Hz, 3-Phase
Operating Temperature (Heating)	-15°C to 24°C
