Fig.7-126: Location of connector
POWER
CR760
!
Non-CE marking
specification
CE marking speci-
fication
A
View A: Inside of CR760 controller
<CR750 controller> <CR751 controller>
<CR760 controller>
CNUSR2 connector
Safety unit
(R760 SFT)
EMG2 connector
