Mitsubishi Electric Hydrobox EHSD-VM2D - Engineers Forms

32
6
Service and Maintenance
en
(Continued to next page.)
Engineers Forms
Commissioning/Field settings record sheet
Main remote controller screen
Parameters
Default setting
Field set-
ting
Notes
Setting Initial settings
Language EN/FR/DE/SV/ES/IT/DA/NL/FI/NO/PT/BG/PL/CZ/RU/
TR
EN
°C/°F °C/°F
°C
Summer time On/Off
Off
Temp. display Room/DHW tank/Room&DHW tank /Off
Off
Time display hh:mm/hh:mm AM/AM hh:mm
hh:mm
Room sensor settings for Zone1 TH1/Main RC/Room RC1-8/“Time/Zone”
TH1
Room sensor settings for Zone2 *1 TH1/Main RC/Room RC1-8/“Time/Zone”
TH1
Room RC zone select *1 Zone1/Zone2
Zone1
Service menu Thermistor adjustment THW1
−10°C - +10°C
0°C
THW2
−10°C - +10°C
0°C
THW5B
−10°C - +10°C
0°C
THW6
−10°C - +10°C
0°C
THW7
−10°C - +10°C
0°C
THW8
−10°C - +10°C
0°C
THW9
−10°C - +10°C
0°C
THW10
−10°C - +10°C
0°C
THWB1
−10°C - +10°C
0°C
Auxiliary settings Economy settings
for pump.
On/Off *6
On
Delay (3 - 60 min) 10 min
Electric heater
(Heating)
Space heating: On (used)/Off (not used) On
Electric heater delay timer (5 - 180 min) 30 min
Electric heater
(DHW) *13
Booster heater
DHW: On (used)/Off (not used) On
Immersion heater
DHW: On (used)/Off (not used) On
Electric heater delay timer (15 - 30 min) 15 min
Mixing valve control
Running (10 - 240 sec) 120 sec
Interval (1 - 30 min) 2 min
Flow sensor *18
Minimum(0 - 100L/min) 5 L/min
Maximum(0 - 100L/min) 100 L/min
Analog output
Interval (1 - 30 min) 5 min
Priority(Normal/High) Normal
Pump speed DHW Pump speed(1 - 5) 5
Heating/Cooling Pump speed(1 - 5) 5
Heat source setting Standard/Heater/Boiler/Hybrid *7 Standard
Heat pump ow rate range Minimum(0 - 100L/min) 5 L/min
Maximum(0 - 100L/min) 100 L/min
Operation
settings
Heating opera-
tion
*8
Flow temp.range
*10
Min.temp.(20 - 45°C) 30°C
Max.temp.(35 - 60°C) 50°C
Room temp.
control
*15
Mode(Normal/Fast) Normal
Interval(10 - 60min) 10min
Heat pump thermo
diff.adjust
On/Off *6 On
Lower limit(−9 - −1°C) −5°C
Upper limit(+3 - +5°C) 5°C
Freeze stat function *11 Outdoor ambient temp. (3 - 20°C) / ** 5°C
Simultaneous operation (DHW/
Heating)
On/Off *6 Off
Outdoor ambient temp. (−30 - +10°C) *3 −15°C
Cold weather function On/Off *6 Off
Outdoor ambient temp. (−30 - −10°C) *3 −15°C
Boiler operation Hybrid settings Outdoor ambient temp.
(−30 - +10°C) *3
−15°C
Priority mode
(Ambient/Cost/CO
2
) *17
Ambient
Outdoor ambient temp. rise (+1 - +5
°C)
+3 °C
Intelligent
settings
Energy
price
*9
Electricity (0.001 - 999 */kWh) 0.5 */kWh
Boiler (0.001 - 999 */kWh) 0.5 */kWh
CO
2
emis-
sion
Electricity
(0.001 - 999 kg -CO
2
/kWh)
0.5 kg -CO
2
/
kWh
Boiler (0.001
- 999 kg -CO
2
/
kWh)
0.5 kg -CO
2
/
kWh
Heat
source
Heat pump capacity
(1
- 40 kW)
11.2 kW
Boiler efciency
(25
- 150%)
80%
Booster heater 1 capacity
(0
- 30 kW)
2 kW
Booster heater 2 capacity
(0
- 30 kW)
4 kW
