4
Technical Information
3
en
Model name EHSE-YM9ED EHSE-MED EHPX-MED EHPX-VM2D EHPX-VM6D EHPX-YM9D EHPX-YM9ED
Overall unit dimensions (Height × Width × Depth) 950 × 600 × 360 mm 800 × 530 × 360 mm
Weight (empty) 63 kg 61 kg 28 kg 35 kg 37 kg 37 kg 32 kg
Weight (full) 73 kg 71 kg 29 kg 40 kg 41 kg 41 kg 37 kg
Water volume of heating circuit in the unit *1 10.0 kg 10.0 kg 1.0 kg 4.5 kg 4.5 kg 4.5 kg 4.5 kg
Plate heat exchanger (MWA1) — — — — — — —
Plate heat exchanger (MWA2-38PA-4) — — — — — — —
Plate heat exchanger (MWA2-72PA)
— — — — —
Unvented expansion
vessel(Primary heating)
Nominal volume — — — 10 L —
Charge pressure — — — 1 bar —
Safety
device
Water
circuit
(Primary)
Control thermistor 1 - 80°C
Pressure relief valve 0.3 MPa (3bar)
Flow sensor Min. ow 5.0 L/min
Booster
heater
Manual reset thermostat 90°C — — 90°C
Thermal Cut-out (for dry run prevention) 121°C — — 121°C
Primary circuit circulating Pump
Grundfos UPMXL
25-125 180
Grundfos UPM3 15-75 130
Connections
Water (primary circuit) G1-1/2-B G1- A
Refrigerant
(R410A)
Liquid 9.52 mm — — — — —
Gas 25.4 mm (Brazing) — — — — —
Target temperature
range
Flow
temperature
Heating 20 - 60°C
Cooling —
Room
temperature
Heating 10 - 30 °C
Cooling —
Guaranteed operat-
ing range
Ambient *2 0 - 35°C (
80 %RH)
Outdoor
temperature
Heating See outdoor unit spec table
Cooling —
Electrical data
Control board
(Including 4
pumps)
Power supply
(Phase, voltage, frequency)
~/N, 230 V, 50 Hz
Breaker
(*when powered from independent source)
10A
Booster
heater
Power supply
(Phase, voltage, frequency)
3~, 400 V,
50 Hz
— —
~/N, 230 V,
50 Hz
~/N, 230 V,
50 Hz
3~, 400 V,
50 Hz
3~, 400 V,
50 Hz
Capacity
3kW
+6kW
— — 2kW
2kW
+4kW
3kW
+6kW
3kW
+6kW
Current 13A — — 9 A 26 A 13A 13A
Breaker 16A — — 16 A 32 A 16A 16A
Sound power level 45 dB(A) 40 dB(A)
<Table 3.2>
*1 Piping to Expansion vessel is not included in this value.
*2 The environment must be frost-free.
*3 Cooling mode is not available in low outdoor temperature.
If you use our system in cooling mode at the low ambient temperature (10°C or below), there are some risks of plate heat exchanger breaking by frozen water.
