4-2. External dimensions
(1) When using L-fittings
(2) When using DIN rail
Unit: mm (in)
100 (3-15/16)
169 (6-11/16)
172 (6-13/16)
209 (8-4/16) 241 (9-8/16)
253 (10)
100 (3-15/16)
39
(1-9/16)
L-fitting
(supplied)
L-fitting
(supplied)
DIN rail attachment
(supplied)
46 (1-13/16)
DIN rail auxiliary
bracket
(supplied)
DIN rail
23 (15/16)
150 (5-15/16)
