6.14 Sampling Trace Function
6 - 77
6.14 Sampling Trace Function
(1) Definition
This function samples the data of the specified device at a preset timing and at a preset interval
(sampling cycle), and then stores the trace results in the sampling trace file.
íç1
(2) Application
This function is useful to check the change of the device data used in the program during debugging at
a preset timing.
In addition, this function is used to read the device data at trigger condition establishment.
(3) Sampling trace file
This file stores the trace setting necessary for executing the function and trace results.
Sampling trace file can be stored only in the Standard RAM or SRAM card. ( Section 5.1.1)
注1
Note6.7
Note6.7
The Q00UJCPU does not support the sampling trace function.
Universal
