Why does the Mitsubishi Electric Controller servo motor not rotate?
If the Mitsubishi Electric Controller's servo motor does not rotate, check the cumulative command pulses, as there might be a wiring mistake. Also, consider that no pulses might be input.
Why is the LED not lit or flickering on my Mitsubishi Electric MR-E-20A?
If the LED on your Mitsubishi Electric Controller is not lit or flickers, it could be due to several reasons: a power supply voltage fault, a faulty servo amplifier, a shorted power supply of CNP1 cabling, a shorted power supply of encoder cabling, a faulty encoder, or a shorted power supply of CN3 cabling.
What to do if the Mitsubishi Electric MR-E-20A Controller servo motor shaft is not servo-locked?
If the Mitsubishi Electric Controller's servo motor shaft is not servo-locked (is free), first, check the display to see if the servo amplifier is ready to operate. This issue might be due to the servo-on signal not being input, potentially caused by a wiring mistake. Also, verify if 24VDC power is supplied to COM. You can check the external I/O signal indication to see if the servo-on (SON) signal is ON.
Why is the Mitsubishi Electric MR-E-20A Controller servo motor running in reverse?
If the Mitsubishi Electric Controller's servo motor runs in the reverse direction, it could be due to a mistake in the wiring to the controller or a mistake in the setting of parameter No. 54.
General| Series | MR-E |
|---|---|
| Rated Output | 200W |
| Feedback resolution | 131072 pulses/rev |
| Protection functions | Overcurrent, Overvoltage, Overload, Overheat, Encoder error, Regenerative error |
| Ambient temperature | 0°C to 55°C (non-freezing) |
| Storage temperature | -20°C to 65°C |
| Ambient humidity | 90% RH or less (non-condensing) |
| Vibration resistance | 5.9 m/s² (0.6G) at 10 to 55 Hz |
Indicates conditions that may cause death or severe injury.
Indicates conditions that may cause medium/slight injury or physical damage.
Correct procedures for connecting electrical components.
Critical safety statement for product application and risk mitigation.
Initial checks and procedures before powering on the system.
Steps for initiating operation, including control mode selection.
Comprehensive list of all available parameters and their functions.
Detailed explanations of parameter functions and settings.
Overview of methods for tuning servo system gains.
Automatic process to optimize servo gains based on machine characteristics.
Procedures for diagnosing and resolving system alarms and warnings.
Comprehensive list of all parameters and their functions.
Identifying and resolving issues encountered during initial startup.
Comprehensive list of alarms, warnings, and their causes.
