9 - 11 9 - 11
MELSEC-Q
9 PROGRAMMING
9.2 Program Example for Normal System Configuration
9.2.1 System configuration and program conditions
(1) System configuration
A program will be explained as an example to realize the following specifications
for the setting target QJ71MT91 (192.1.0.1).
1: This QJ71MT91 is assumed to be mounted in Slot 0 of the base unit with
the head I/O No. set to 0.
