'14 KX-SM-221
(3)
Outdoor fan control
(a)
Outdoor fan speed and fan motor rotation speed
The 7th outdoor fan speed in the following table is specified as the rated speed. Under the normal control, the speeds up
to 9th level are used.
Note (1) Heating 9th speed changes it depending to outdoor air temperature Tho-A as follows.
(b)
Fan control during cooling
During cooling and dehumidifying, fan speed is controlled in accordance with the high pressure (sensed by PSH) and the
outdoor air temperature (sensed by Tho-A).
(i)
Initial fan speeds are as follows.
Initial ourdoor fan speed at cooling
(ii)
Speed changes depending on high pressure value.
(iii)
Under low outdoor air temperature condition, the stepless fan control between 130-300min
-1
is performed.
Outdoor fan tap
Cooling Heating
FMo1 [min
-1
] FMo2 [min
-1
] FMo1 [min
-1
] FMo2 [min
-1
]
0th speed 0 0 0 0
1th speed 200 0 200 0
2th speed 200 200 200 200
3th speed 300 300 300 300
4th speed 390 390 390 390
5th speed 530 530 530 530
6th speed 600 600 600 600
7th speed 730 730 730 730
8th speed 825 825 825 825
Model Outdoor air temp. ≤ 10ºC
10ºC < Outdoor air temp. < 15ºC
15ºC ≤ Outdoor air temp.
All models 2th speed 4th speed 6th speed
950min
-1
900min
-1
3 6
Outdoor air temperature Tho-A (℃)
9th speed 900 900 900/950 900/950
The fan speed control is performed based on the low pressure (detected with PSL) during heating operation.
Initial fan speed is 6th speed.
Speed changes depending on low pressure value.
