202
-
(d) Explain to the customer on the correct usage of the air conditioner in simple layman’s terms.
(e) Make sure that drain flows properly.
(f) Standard operation data
Model
Item
SRK50HE-S1 SRK56HE-S1
Cooling ––
Heating 2.6~2.8 2.8~3.0
Cooling 0.8~1.0 0.8~1.0
Heating ––
Cooling 14~16 15~17
Heating 20~22 23~25
Cooling 6.5/6.3/6.0 7.3/7.1/6.8
Running current (A)
Heating 6.5/6.2/6.0 7.4/7.1/6.8
Low pressure (MPa)
Temp. difference between
return air and supply air (°C)
High pressure (MPa)
(220/230/240V)
Model
Item
SRK50CE-S1 SRK56CE-S1
Cooling 0.8~1.0 0.8~1.0
Cooling 14~16 15~17
Cooling 6.5/6.3/6.0 7.3/7.1/6.8
Note (1) The data are measured at following conditions
Ambient air temperature
Indoor side: Cooling ... 27ËšC DB, 19ËšC WB, Heating ... 20ËšC DB
Outdoor side: Cooling ... 35ËšC DB, 24ËšC WB, Heating ... 7ËšC DB, 6ËšC WB
Low pressure (MPa)
Temp. difference between return air and supply air (°C)
Running current (A)
(ii) When manipulating the remote controller mounted on
a wall:
Make sure that it works normally (i.e., transmission/reception
signal is audible) before mounting.
Notes (1) The remote controller is correctly facing the
sensing element of the air conditioner when being
manipulated.
(2) The typical coverage is indicated (in the left
illustration). It may be more or less depending on
the installation.
(3) The coverage may be less or even nil. If the sensing
element is exposed to strong light, such as direct
sunlight, illumination, etc., or dust is deposited on
it or it is used behind a curtain, etc.
or less
5 m or less
Wireless remote
controller
5 m or less
Remote controller
available in this area.
Receiver
or less
(6) Precautions for wireless remote controller installation and operation
(a) Wireless remote controller covers the following distances:
(i) When operating facing the air conditioner:
or less
