(2) Range of usage & limitations
(3) Exterior dimensions
Indoor return air temperature
(Upper, lower limits)
Refrigerant line (one way) length
All models
Cooling operation : Approximately 21 to 32˚C
Cooling operation : Approximately 21 to 43˚C
Power source voltage Rating ± 10%
Voltage at starting Min. 85% of rating
Max. 25m
Max. 15m
Frequency of ON-OFF cycle Max. 10 times/h
ON and OFF interval Max. 3 minutes
Outdoor air temperature
(Upper, lower limits)
Vertical height difference between
outdoor unit and indoor unit
Item
Models
(a) Indoor unit
Models SRK63CE-S1, 71CE-S1
VIEW A
A
17.360
150
4
43.5
55
64
489
Piping hole right (left)
3
248
55
4
19 51.2
55
Terminal block
1090
Unit: mm
318
77
44.5
7.7
299
106
8.5301.8
25
50
Installation board
450
50
25
Piping for Gas
63: ø12.7
633.5
71: ø15.88
44.5
53.5
106
49.5
349
886
221.547
Indoor unit
1098
Piping for Liquid (ø6.35) 703.5
Drain hose 772 (ø16)
Piping hole (ø65)
Piping hole (ø65)
