4G9 ENGINE (E-W) -
Specifications
11A-1-6
Items Nm
EGR valve 18
Engine hanger 18
EGR valve support bolt 18
EGR valve support nut 23
Air by-pass valve 9
Intake manifold and exhaust manifold
Exhaust manifold (M10) 29
Exhaust manifold (M8) 18
Exhaust manifold bracket 19
Engine hanger 12
Oil level gauge guide 14
Boost sensor 5
Intake air temperature sensor 13
Heat protector 13
Intake manifold 20
Intake manifold stay 30
Intake manifold (GDI)
Vacuum pipe and hose <For CARISMA> 11
Vacuum pipe and hose <For PAJERO io> 9
Solenoid valve 9
Fuel pump protector 23
Connector bracket 11
Branch tube (M6 x 18) 9
Branch tube (M6 x 14) 11
Intake manifold stay 30
Accelerator cable bracket 9
Vacuum pipe 11
Intake manifold 19
Exhaust manifold (GDI)
Oil level gauge guide 13
Exhaust manifold cover 13
Engine hanger bolt 18
Engine hanger nut (M8) 18
Engine hanger nut (M10) 29
Exhaust manifold bracket (M8 ´ 22) 35
Exhaust manifold bracket (M8 ´ 20) 18
Exhaust manifold bracket (M10) 98
Exhaust manifold (M10) 29
PWEE9502-E
E
Dec. 1998Mitsubishi Motors Corporation Revised

Mitsubishi 4G93 Specifications

General

Bore x Stroke	81.0 mm x 89.0 mm
Block Material	Cast iron
Engine code	4G93
Displacement	1834 cc
Compression Ratio	9.5:1
Fuel System	Multi-point fuel injection
Valvetrain	DOHC, 16 valves
Torque	167 Nm
Head Material	Aluminum
Fuel type	Petrol
Engine Type	Inline 4 cylinder
