Installing direction
Install the memory
IC
into the direc-
EP-ROM
installing
directior
tion marked on the memory socket
matching the notch position.
If
in-
stalled in wrong direction, the
memory will be destroyed when the
A2C
is turned on.
Fig.
5.2
Installing
Direction
(3)
Procedure
a)
Set memory type with the memory select switch.
1)
Sequence programs stored in the user memory area
in
the
A2C
is used:
OFF
2)
EP-ROM
is
installed:
ON
b) Install the EP-ROM.
Match the notch mark on the ROM socket with the notch
of
the EP-ROM.
After installing the EP-ROM, cover
it
with the masking tape
supplied with the ROM.
L-
5-2
IB
INAI
6623EA
---
