Mitsubishi A2SHCPU (S1) User Manual

11 - 16
TROUBLESHOOTING11.
Table 11.1 AnSHCPU Error Code List (Continue)
Error Message
Error
Code
(D9008)
Detailed
Error
Code
(D9092)
CPU
module
status
Error and Cause Corrective Action
"LINK PARA.
ERROR"
47 — Stop
(Continue)
(1) There is inconsistency for some rea-
son between the data, which is writ-
ten by the peripheral device in the
parameter area of the link under
link range designation using param-
eter setup, and the link parameter
data read by the CPU module.
(2) The total number of stations is set at
"0."
(1) Write parameters and check again.
(2) If the error persists, there is a fault in
hardware. Consult Mitsubishi repre-
sentative.
"OPERATION
ERROR"
(Checked at
instruction
execution.)
50 — Continue
(Stop)
(1) The result of BCD conversion
exceeds the rated range ("9999" or
"99999999").
(2) There is a setting exceeding the
rated device range, disabling execu-
tion of calculation.
(3) The file register is used on the pro-
gram without designation of the
capacity of the file register.
Use the peripheral device to read and
correct the error step in the program.
(Check the setting range of the device,
BCD conversion value and so on.)
503 The data stored by the designated
device or a constant exceeds the
allowable range.
Use the peripheral device to read and
correct the error step in the program.
504 The setting quantity of handled data
exceeds the allowable range.
509 The number of special instructions for
CC-Link executed in each scan
exceeds 64.
Reduce the special instructions for CC-
Link executed in each scan to within 64.
A special instruction for CC-Link is
executed to a CC-Link module to which
no parameter is defined.
Define parameters.
"MAIN CPU
DOWN"
60 — Stop (1) The CPU malfunctioned due to
noise.
(2) Hardware failure.
(1) Take proper countermeasures for
noise.
(2) Consult Mitsubishi representative.
"BATTERY
ERROR"
(Always
checked.)
70 — Continue (1) The battery voltage is low.
(2) The battery lead connector is not
connected.
(1) Replace the battery.
(2) Connect the lead connector to use
the built-in RAM memory or power
failure compensation function.
