Mitsubishi A2SHCPU (S1) User Manual

2 - 20
SYSTEM CONFIGURATION2.
Graphic
operation
terminal
A985GOT
Large-size graphic operation terminal
256 colors, TFT color, 800 600 dots, high intensity
32
[32 special
points]*
0.22 * –
*When bus
connected
A975GOT
Large-size graphic operation terminal
256 colors, TFT color, 640 480 dots, high intensity
A970GOT
Large-size graphic operation terminal
16 colors, TFT color, 640 480 dots, high intensity/
16 colors, TFT color, 640 480 dots, wide viewing
angle/
8 colors, STN color, 640 480 dots/
2 colors, STN monochrome, 640 480 dots
A960GOT
Large-size graphic operation terminal
2 colors, EL, 640 400 dots
A956GOT
Medium-size graphic operation terminal
8 colors, STN color, 320 240 dots/
STN monochrome, 320 240 dots/
256 colors, TFT color 320 240 dots
A956WGOT
Medium-size graphic operation terminal
256 colors, TFT color 480 234 dots
A953GOT
Medium-size graphic operation terminal
8 colors, STN color, 320 240 dots/
STN monochrome, 320 240 dots/
256 colors, TFT color 320 240 dots
–––
For RS-232C
connected only
A951GOT
Medium-size graphic operation terminal
8 colors, STN color, 320 240 dots/
STN monochrome, 320 240 dots/
256 colors, TFT color 320 240 dots
32
[32 special
points]*
0.22 * –
*When bus
connected
A950GOT
Medium-size graphic operation terminal
8 colors, STN color, 320 240 dots/
STN monochrome, 320 240 dots/
256 colors, TFT color 320 240 dots
–––
For RS-422
connected only
GT1565-
VTBA
Large-size graphic operation terminal 8.4"
256/65536 colors, TFT color, 640 480 dots
(When installing a multi color display board, 65536
colors can be displayed.)
32
[32 special
points]*
0.12 –
*When bus
connected
GT1575-
VTBA
Large-size graphic operation terminal 10.4"
256/65536 colors, TFT color, 640 480 dots
(When installing a multi color display board, 65536
colors can be displayed.)
Main base unit
A1S32B 2 I/O modules can be installed.
–––
Extension
connector on the
right and left side
each.
A1S33B 3 I/O modules can be installed.
A1S35B 5 I/O modules can be installed.
A1S38B 8 I/O modules can be installed.
Product Name Model Name Description
Number of occupied points
(points)
[I/O Assignment
Module Type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
