Mitsubishi A2SHCPU (S1) User Manual

2 - 19
SYSTEM CONFIGURATION2.
PC easier
monitoring
module
A1SS91 PC easier monitoring module 16
[16 special
points]
0.08 –
Memory card
interface
module
A1SD59J-S2 Memory card interface module 32
[32 special
points]
0.05 –
The current con-
sumption
describes in
connecting
A1SD59J-MIF.
Simulation
module
A6SIM-
X64Y64
An I/O simulation unit used connected to the base
module.Debugging can be executed without
connecting the I/O module to the base module.Use
an expansion cable of the AnS series between the
main base of the AnS series and the A6SIM-
X64Y64.
64
64
[64 input points]
[64 output points]
TYP. 0.3
(When
all points
ON)
–
PROFIBUS
interface
module
A1SJ71PB92
D
PROFIBUS-DPmaster module 32
[32 special
points]
0.56 –
A1SJ71PB96
F
PROFIBUS-FMS interface module 32
[32 special
points]
0.56 –
Device Net
interface
module
A1SJ71DN91 Device net master module 32
[32 special
points]
0.24 –
MODBUS
interface
module
A1SJ71UC24
-R2-S2
RS-232Ctype MODBUS interface module 32
[32 special
points]
0.1 –
A1SJ71UC24
-R4-S2
RS-422/485type MODBUS interface module 32
[32 special
points]
0.1 –
Product Name Model Name Description
Number of occupied points
(points)
[I/O Assignment
Module Type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
