Mitsubishi A2SHCPU (S1) User Manual

2 - 18
SYSTEM CONFIGURATION2.
MELSECNET(II)
data link
module
A1SJ71AP21
For the master and local stations of
MELSECNET(II) data link system (for the optical
fiber cable)
32
[32 special
points]
0.33 –
Access is allowed
within the device
range of the
AnACPU.
A1SJ71AP21
-S3
For the master and local stations of
MELSECNET(II) data link
(for the GI-type optical fiber cable)
32
[32 special
points]
0.33 –
A1SJ71AR21
For the master and local stations of
MELSECNET(II) data link system (for the coaxial
cable)
32
[32 special
points]
0.8 –
MELSECNET/B
data link
module
A1SJ71AT21
B
For the master and local stations of MELSECNET/
B data link system
32
[32 special
points]
0.66 –
A1SJ72T25B
For the remote I/O station of
MELSECNET/B data link system
–0.3–
B/NET
interface
module
A1SJ71B62-
S3
Master module for B/NET 32
[32 special
points]
0.08 –
MELSECNET/
10 data link
module
A1SJ71LP21
For the control, master, and normal stations of the
MELSECNET/10 data link module system
(For the coaxial cable dual loop)
32
[32 special
points]
0.65 –
A1SJ71LP21
GE
For the control, master, and normal stations of the
MELSECNET/10 data link module system
(For the GI-type optical fiber cable dual loop)
32
[32 special
points]
0.65 –
A1SJ71BR11
For the control, master, and normal stations of the
MELSECNET/10 data link module system
(For the single bus coaxial cable)
32
[32 special
points]
0.80 –
A1SJ71LR21
For the control, master, and normal stations of the
MELSECNET/10 data link module system
(For the coaxial cable dual loop)
32
[32 special
points]
1.14 –
CC-Link system
master module
A1SJ61BT11
For the master and local stations of the CC-Link
data link system
(For the twisted pair shield cable only)
32
[32 special
points]
0.40 –
MELSECNET/
MINI-S3 master
module
A1SJ71PT32
-S3
For MELSECNET/MINI-S3 master stations (max.
64 stations). Performs remote I/O and remote
terminal control of a total of 512 I/O points.
I/O mode
[32 special points]
0.35 –
Expanded mode
48 [48 special points]
MELSECNET-
I/O LINK
master module
A1SJ51T64
MELSECNET-I/O LINK master station.Controls I/O
LINK remote I/O module of a maximum of 16
stations and a total of 128 I/O points.
64
[64 special
points]
0.115 0.09
S-LINK
interface
module
A1SJ71SL92
N
Master module for S-LINK
I/O total 128 points
32
[32 special
points]
0.20 –
AS-I interface
module
A1SJ71AS92
Master module for AS-I
I/O total 496 points
32
[32 special
points]
0.15 –
Positioning
detection
module
A1S62LS Absolute positioning detection module 32
[32 special
points]
0.55 –
*6:0.06A is shown on the rating plate of the module.
Product Name Model Name Description
Number of occupied points
(points)
[I/O Assignment
Module Type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
