SYSTEM CONFIGURATION2.
REMARK
Toa Electric Industrial CO., LTD. provides I/O cables with connectors, which can
connect to 40-pin connector (A1SX41, A1SX42, A1SY41, A1SY41P, A1SY42,
A1SY42P, etc.) or 37-pin D-sub connector (A1SX81, A1SY81) of I/O modules.
Contact:
TOA ELECTRIC INDUSTRIAL CO., LTD.
Cable for
connecting the
relay terminal unit
AC06TE 0.6m (1.97ft.) long
A6TE2-16SRN
AC10TE 1m (3.28ft.) long
AC30TE 3m (9.84ft.) long
AC50TE 5m (16.40ft.) long
AC100TE 10m (32.81ft.) long
Terminal block
cover for the A1S
I/O module and the
special module
A1STEC-S
Slim-type terminal block cover for the A1S I/O
module and the special module (terminal block
connector type).
All terminal block connector type modules
IDC terminal block
adapter
A1S-TA32
IDC terminal block adapter for 32 points 0.5mm
2
(AWG20)
A1SX41(S1/S2), A1SX71, A1SY41, A1SY71A1S-TA32-3
IDC terminal block adapter for 32 points 0.3mm
2
(AWG22)
A1S-TA32-7
IDC terminal block adapter for 32 points 0.75mm
2
(AWG18)
Terminal block
adapter
A1S-TB32
For 32 points, conversion into Europe type terminal
block
A1SX41(S1/S2), A1SX71, A1SY41, A1SY41P, A1SY71
40-pin connector
A6CON1 Soldering-type, straight out
Sink type (40p FCN)
A6CON2 Crimp type, straight out
A6CON3 Insulation-displacement type, flat cable
A6CON4 Soldering-type, straight/diagonal out
3-pin D-sub
connector
A6CON1E Soldering-type, straight out
Source type (37p D-sub)A6CON2E Crimp type, straight out
A6CON3E Insulation-displacement type, flat cable
Product Name Model Name Description Applicable Model
