2 - 24
SYSTEM CONFIGURATION2.
(2) Peripheral device
Product Name Model Name Remark
Plasma hand-held
graphic programmer
A6PHP-SET
• A6PHP main unit
• SW GP-GPPA........
• SW GP-GPPK........
• SW0-GPPU...............
• AC30R4....................
GPP function start-up floppy disk for the A series
GPP function start-up floppy disk for the K series
User floppy disk (2DD)
RS-422 cable 3m (9.84 ft.)-long
Intelligent GPP A6GPP-SET
• A6GPP main unit
• SW GP-GPPA.........
• SW GP-GPPK.........
• SW0-GPPU................
• AC30R4.....................
GPP function start-up floppy disk for the A series.
GPP function start-up floppy disk for the K series.
User floppy disk (2DD).
RS-422 cable 3m (9.84 ft.)-long
Composite video cable AC10MD • Connection cable for the monitor display of the A6GPP screen: 1m (3.28 ft.) long
RS-422 cable
AC30R4 3m (9.84ft.) long
Connection cable for between the CPU main module and
A6GPP/A6PHP
AC300R4 30m (98.43ft.) long
User floppy disk SW0S-USER 2HD-type
Floppy disk for storing user programs
(3.5-inch, pre-formatted)
Floppy disk for cleaning SW0-FDC For A6GPP/A6PHP Floppy disk for cleaning the floppy disk drive.
Optional keyboard for
A6PHP
A6KB-SET-H
• A6KB keyboard
• AC03R4H..............
• A6KB-C.................
Connection cable between A6KB and A6PHP: 0.3m
(0.98 ft.) long
Key sheet for the GPP mode of A6KB
Optional keyboard for
A6GPP
A6KB-SET
• A6KB keyboard
• AC03R4L.............
• A6KB-C................
Connection cable between A6KB and A6GPP: 0.3m
(0.98 ft.) long
Key sheet for the GPP mode of A6KB.
