2 - 25
SYSTEM CONFIGURATION2.
Product Name Model Name Remark
Printer
K6PR-K
A7NPR-S1
• For printing out program circuit diagrams and various lists
RS232C cable AC30R2
Connection cable for between A6GPP/A6PHP and printer (K6PR-K, A7NPR-S1,
and a general-purpose printer with RS-232C interface)
3m (9.84ft.) long
Printer paper
K6PR-Y
K7PR-Y
Printer paper for K6PR(S1) and K6PR-K, 9-inch paper, Unit: 2000 sheets
Printer paper for A7PR and A7NPR, 11-inch paper, Unit: 2000 sheets
Inked ribbon for
K6PR(K)
K6PR-R Replacement inked ribbon for K6PR-K.
Programming module
A7PUS
Read/write of the program is performed by connecting to the CPU main module
with a RS-422 cable (AC30R4-PUS). (5VDC 0.4A)
A8PUE
Read/write of the program is performed by connecting to the CPU main module or
a RS-422 cable (AC30R4-PUS, AC20R4-A8PU). (5VDC 0.4A)
RS-422 cable
AC30R4-PUS
Connection cable for between the CPU main module and A7PUS, A8PUE
3m (9.84ft.) long
AC20R4-A8PU
Connection cable for between the CPU main module and A8PUE
2m (6.56ft.) long
Data access module A6DU-B
• Used for monitoring the devices of the CPU module, changing the setting values/
current values, and displaying the operation status. (5VDC 0.23A)
• Connect to the CPU mopdule with an AC30R4-PUS cable.
Modem interface
module
A6TEL
• An interface module which connects the CPU module and the modem. Using a
telephone line, the communication is performed between a remote peripheral
device and the CPU module. (5VDC 0.2A)
• Connect to the CPU mopdule with an AC30R4-PUS cable.
RS-422 cable
AC30R4
AC300R4
Connection cable for between the CPU main unit and A6WU: 3m/30m (9.84 ft./
98.43 ft.) long
AC03WU Connection cable for between the A6PHP main unit and A6WU: 0.3m (0.98ft.) long
