Monitor DiamondPoint V50LCD Notes
Specifications Monitor
LCD Module Diagonal : 15.0 inch Active matrix; thin film transistor (TFT)
Viewable Image Size : 15.0 inch liquid crystal display (LCD); 0.297 mm dot
Native Resolution (Pixel Count) : 1024 x 768 pitch; 300cd/m
2
white luminence;
500:1 contrast ratio, typical
Input Signal Video : ANALOG 0.7 Vp-p/75 Ohms
Sync : Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Display Colors Analog input : 16,194,277 Depends on display card used.
Maximum Left/Right : 70°/70°
Viewing Angles Up/Down : 55°/65°
Synchronization Horizontal : 31.5 kHz to 60 kHz (Analog) Automatically
Range Vertical : 56.0 Hz to 75.0 Hz Automatically
Resolutions Supported 720 x 400*
1
:VGA text Some systems may not support all modes listed.
640 x 480*
1
@ 60 Hz to 75 Hz
800 x 600*
1
@ 56 Hz to 75 Hz
832 x 624*
1
@ 75 Hz
1024 x 768 @ 60 Hz to 75 Hz ..............
NEC-Mitsubishi Electronics Display cites
recommended resolution at 60 Hz for
optimal display performance.
Active Display Area Horizontal : 304 mm/12.0 inches
Vertical : 228 mm/9.0 inches
Power Supply AC100 - 240V, 50/60 Hz
Current Rating 0.6A @ 100-120V, 0.35A @ 220-240V
Dimensions 356 mm (W) x 356.5 mm (H) x 150 mm (D)
14.0 inches (W) x 14.0 inches (H) x 5.9 inches (D)
Weight 3.0 kg
6.4 lbs
Environmental Considerations
Operating Temperature : 5°C to 35°C/41°F to 95°F
Humidity : 30% to 80%
Feet : 0 to 12,000 Feet
Storage Temperature : -10°C to 60°C/14°F to 140°F
Humidity : 10% to 85%
Feet : 0 to 40,000 Feet
*
1
Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
Specifications
DPVLCDmanualFINAL.P65 10/27/03, 12:42 PM9
