3
Quick Start
Attaching / Removing the Base
Install
Align the two hooks on the bottom of the
monitor with the corresponding slots on
the bottom of the base.
Remove
Depress the hooks as indicated first
before removing the base and follow the
arrow direction to remove it.
Insure the lock is hooked completely.
Screen Position Adjustment
In order to optimize the best viewing position, you can adjust the tilt of the monitor
by using both of your hands to hold the edges of the monitor as shown in the figure.
The monitor can be adjusted to 25 degrees up or -5 degrees down as indicated by
arrow.
NOTE:NOTE:
NOTE:NOTE:
NOTE: Handle with care when attaching or removing the base.
DPVLCDmanualFINAL.P65 10/27/03, 12:42 PM3
