MANUAL TRANSMISSION (E-W) -
Specifications
22B-1-4
SNAP RINGS, SPACERS AND THRUST PLATE ADJUSTMENT
Part name Thickness mm Identification
symbol
Part No.
Snap ring 2.24 None MD706537
(For adjustment of input shaft front bearing end
play)
2.31 Blue MD706538
2.38 Brown MD706539
Snap ring 2.31 Black (2) MD747149
(For adjustment of input shaft rear bearing end
play ....F5M41)
2.35 None MD746561
(For adjustment of output shaft rear bearing end
play ....F5M42, W5M42)
2.39 Blue MD746562
2.43 Brown MD746563
2.47 Green MD746564
2.51 White MD746565
2.55 Yellow MD746566
2.59 Black MD746567
2.63 Orange MD746568
2.67 Blue MD746569
2.71 Brown MD746570
Thrust plate: F5M42, W5M42 2.82 - MD748015
(For adjustment of input shaft 5th speed gear
end play)
2.86 - MD748016
2.90 - MD748017
2.94 - MD748018
2.98 - MD748019
3.02 - MD748020
3.06 - MD748021
3.10 - MD748022
Snap ring 1.43 Green (2) MD746708
(For adjustment of output shaft front bearing end
play)
1.51 White (2) MD746709
(For adjustment of input shaft rear bearing end
play ....F5M42, W5M42)
1.59 Yellow (2) MD746710
PWEE9508-F
E
July 1999Mitsubishi Motors Corporation Revised
