MANUAL TRANSMISSION (E-W) -
Input Shaft <F5M41>
22B-5-3
PWEE9508-A
E
Nov. 1995Mitsubishi Motors Corporation Added
A
F
"
BALL BEARING REMOVAL
REASSEMBLY SERVICE POINTS
"
A
A
OIL SEAL INSTALLATION
Drive in the oil seal all the way up to the illustrated dimension.
"
B
A
BALL BEARING INSTALLATION
"
C
A
SNAP RING INSTALLATION
Select a n d install a snap ring so that the input shaft front
bearing e n d play will have the standard value.
Standard value:
-0.01-0.12 mm
"
D
A
SYNCHRONIZER SPRING INSTALLATION
Install the synchronizer spring securely up to the illustrated
position of t he synchronizer ring.
MD998801
3.5 mm
Oil seal
MD998812
MD998813
MD998817
MD998801
Snap ring
Synchronizer spring
