MANUAL TRANSMISSION (E-W) -
Output Shaft
22A-4-2
PWEE9508
E
May 1995Mitsubishi Motors Corporation
DISASSEMBLY AND REASSEMBLY <F5MR3>
2
3
4
5
1
6
12
13
16
17
18
19
20
21
10
15
14
11
RMT0024
16
5
8
7
9
Lubricate all internal
parts with gear oil
during reassembly.
Disassembly steps
1. Bearing
2. Shim
A
A
""
O
A
3. 4th gear wheel
4. Synchronizer ring
A
H
""
M
A
5. Bearing bushing
6. 3rd - 4th gear synchronizer sleeve
A
I
"
7. Synchronizer spring
8. Roller
"
L
A
9. 3rd - 4th gear synchronizer hub
A
H
""
J
A
10. 3rd gear wheel
A
H
""
H
A
11. Bearing bushing
12. Shim
A
H
""
G
A
13. 2nd gear wheel
A
H
""
E
A
14. Bearing bushing
15. 1st - 2nd gear synchronizer sleeve
A
I
""
B
A
16. Synchronizer spring
A
H
""
D
A
17. 1st - 2nd gear synchronizer hub
18. Synchronizer ring
A
H
""
A
A
19. 1st gear wheel
20. Output shaft
A
J
""
C
A
21. Bearing cup
RevisedPWEE9508-BMitsubishi Motors Corporation
May 1996
