MANUAL TRANSMISSION (E-W) -
Specifications
22A-1-1
1. SPECIFICATIONS
GENERAL SPECIFICATIONS
Items Specifications
Model F5MR1 <For CARIS-
MA>, F5MR2
F5MR1
<For SPACE STAR>
F5MR3
Type Manual, 5-speed,
front wheel drive
Manual, 5-speed,
front wheel drive
Manual, 5-speed,
front wheel drive
Gear ratio 1st 3.363 3.727 3.727
2nd 2.047 2.047 2.047
3rd 1.321 1.321 1.321
4th 0.966 0.966 0.971
5th 0.794 0.794 0.756
Reverse 3.545 3.545 3.545
Final reduction ratio 4.066 4.214 3.437
TORQUE SPECIFICATIONS
Items Specifications (Nm)
Bearing housing bolts 25
Input shaft lock nut 135
Output shaft bolt 80
Cover bolts 25
Locating pin 24
Back-up lamp switch 22
Drain plug 22
Filler/level plug 2.25
Sealing plugs 25
Guide bushing bolts <F5MR3> 25
Differential nut <F5MR3> 130
PWEE9508-E
E
Jun. 1998Mitsubishi Motors Corporation Revised
