MANUAL TRANSMISSION (E-W) -
Clutch Housing
22A-6-1
PWEE9508
E
May 1995Mitsubishi Motors Corporation
6. CLUTCH HOUSING
DISASSEMBLY AND REASSEMBLY <F5MR1, F5MR2>
4
6
5
7
3
2
1
8
Lubricate all internal
parts with gear oil
during reassembly.
Disassembly steps
A
A
""
G
A
1. Input shaft bearing
A
C
""
E
A
2. Output shaft bearing
3. Oil baffle
A
E
""
D
A
4. Large bearing
A
F
""
C
A
5. Speedometer drive gear
6. Shaft
7. Snap ring
A
G
""
A
A
8. Small bearing
RevisedPWEE9508-BMitsubishi Motors Corporation
May 1996
E
