MANUAL TRANSMISSION (E-W) -
Clutch Housing
22A-6-2
PWEE9508
E
May 1995Mitsubishi Motors Corporation
DISASSEMBLY AND REASSEMBLY <F5MR3>
4
6
5
7
32
1
RMT0046
Lubricate all internal
parts with gear oil
during reassembly.
Disassembly steps
A
B
""
H
A
1. Input shaft bearing cup
A
D
""
F
A
2. Output shaft bearing
3. Oil baffle
A
C
""
B
A
4. Large bearing cup
A
F
""
C
A
5. Speedometer drive gear
6. Shaft
A
H
""
B
A
7. Small bearing cup
RevisedPWEE9508-BMitsubishi Motors Corporation
May 1996
E
To Next Page
