Mitsubishi F5MR1 User Manual

MANUAL TRANSMISSION (E-W) -
Control Lever
22A-7-1
PWEE9508
E
May 1995Mitsubishi Motors Corporation
7. CONTROL LEVER
22200790010
DISASSEMBLY AND REASSEMBLY
4
6
12
1
14
11
10
2
9
5
13
7
8
3
Lubricate all internal
parts with gear oil
during reassembly.
Disassembly steps
1. Compression spring
2. Snap ring
A
A
""
C
A
3. Remote control arm
4. Spring pin
5. Spring pin
A
A
""
C
A
6. Selector dog
"
B
A
7. Selector shaft oil seal
8. Rubber seal
9. Bearing bushes
A
A
""
C
A
10. Shift lever
11. Rubber seal
12. Rubber seal
A
B
""
A
A
13. Outer bearing bush
A
B
""
A
A
14. Inner bearing bush
