Mitsubishi FR-F500

APPENDICES
196
Data Codes
Func-
tion
Parameter
Number
Name
Read Write
Link Parameter Extension
Setting (Data code 7F/FF)
Additional
function
59 Remote setting function selection 3B BB 0
60 Intelligent mode selection 3C BC 0
61 Reference I for intelligent mode 3D BD 0
62 Ref. I for intelligent mode accel 3E BE 0
63 Ref. I for intelligent mode decel 3F BF 0
65 Retry selection 41 C1 0
66
Stall prevention operation level reduction
starting frequency
42 C2 0
67 Number of retries at alarm occurrence 43 C3 0
68 Retry waiting time 44 C4 0
69 Retry count display erasure 45 C5 0
71 Applied motor 47 C7 0
72 PWM frequency selection 48 C8 0
73 0-5V/0-10V selection 49 C9 0
74 Filter time constant 4A CA 0
75
Reset selection/disconnected PU detection/PU
stop selection
4B CB 0
76 Alarm code output selection 4C CC 0
77 Parameter write disable selection 4D CD (Note) 0
78 Reverse rotation prevention selection 4E CE 0
Operation selection functions
79 Operation mode selection 4F CF (Note) 0
100 V/F1 (first frequency) 00 80 1
101 V/F1 (first frequency voltage) 01 81 1
102 V/F2 (second frequency) 02 82 1
103 V/F2 (second frequency voltage) 03 83 1
104 V/F3 (third frequency) 04 84 1
105 V/F3 (third frequency voltage) 05 85 1
106 V/F4 (fourth frequency) 06 86 1
107 V/F4 (fourth frequency voltage) 07 87 1
108 V/F5 (fifth frequency) 08 88 1
5-point flexible V/F
characteristics
109 V/F5 (fifth frequency voltage) 09 89 1
117 Station number 11 91 1
118 Communication speed 12 92 1
119 Stop bit length/data length 13 93 1
120 Parity check presence/absence 14 94 1
121 Number of communication retries 15 95 1
122 Communication check time interval 16 96 1
123 Waiting time setting 17 97 1
Communication
functions
124 CR
•
LF presence/absence selection 18 98 1
128 PID action selection 1C 9C 1
129 PID proportional band 1D 9D 1
130 PID integral time 1E 9E 1
131 Upper limit 1F 9F 1
132 Lower limit 20 A0 1
133 PID action set point for PU operation 21 A1 1
PID control
134 PID differential time 22 A2 1
135
Commercial power supply-inverter switch-over
sequence output terminal selection
23 A3 1
136 MC switch-over interlock time 24 A4 1
137 Start waiting time 25 A5 1
138
Commercial power supply-inverter switch-over
selection at alarm occurrence
26 A6 1
Commercial power
supply-inverter
switch-over
139
Automatic inverter-commercial power supply
switch-over frequency
27 A7 1
