Mitsubishi FR-F500

APPENDICES
197
Data Codes
Func-
tion
Parameter
Number
Name
Read Write
Link Parameter Extension
Setting (Data code 7F/FF)
140 Backlash acceleration stopping frequency 28 A8 1
141 Backlash acceleration stopping time 29 A9 1
142 Backlash deceleration stopping frequency 2A AA 1
Backlash
143 Backlash deceleration stopping time 2B AB 1
144 Speed setting switch-over 2C AC 1
Dis-
play
145 Parameter unit language switch-over 2D AD 1
148 Stall prevention operation level at 0V input 30 B0 1
Additional
functions
149 Stall prevention operation level at 10V input 31 B1 1
152 Zero current detection level 34 B4 1
Current
detection
153 Zero current detection period 35 B5 1
154
Voltage reduction selection during stall
prevention operation
36 B6 1
155 RT activated condition 37 B7 1
156 Stall prevention operation selection 38 B8 1
157 OL signal output waiting time 39 B9 1
Sub functions
158 AM terminal function selection 3A BA 1
Additional
function
160 User group read selection 00 80 2
162
Automatic restart after instantaneous power
failure selection
02 82 2
163 First cushion time for restart 03 83 2
164 First cushion voltage for restart 04 84 2
Restart after
instantaneous
power failure
165 Restart stall prevention operation level 05 85 2
170 Watt-hour meter clear 0A 8A 2
Initial
monitor
171 Actual operation hour meter clear 0B 8B 2
173 User group 1 registration 0D 8D 2
174 User group 1 deletion 0E 8E 2
175 User group 2 registration 0F 8F 2
User
functions
176 User group 2 deletion 10 90 2
180 RL terminal function selection 14 94 2
181 RM terminal function selection 15 95 2
182 RH terminal function selection 16 96 2
183 RT terminal function selection 17 97 2
184 AU terminal function selection 18 98 2
185 JOG terminal function selection 19 99 2
186 CS terminal function selection 1A 9A 2
190 RUN terminal function selection 1E 9E 2
191 SU terminal function selection 1F 9F 2
192 IPF terminal function selection 20 A0 2
193 OL terminal function selection 21 A1 2
194 FU terminal function selection 22 A2 2
Terminal assignment functions
195 A, B, C terminal function selection 23 A3 2
Additional
function
199 User's initial value setting 27 A7 2
