Mitsubishi FR-F500

PARAMETERS
63
Func-
tion
Parameter
Number
Name Setting Range
Minimum
Setting
Increments
Factory
Setting
〈
〈〈
〈EC
Version〉
〉〉
〉
Refer
To
Page:
Cust-
omer
Set-
ting
152 Zero current detection level 0 to 200.0% 0.1% 5.0% 133
Current
detection
153 Zero current detection period 0 to 1 s 0.01 s 0.5 s 133
154
Voltage reduction selection during stall
prevention operation
0, 1 1 1 77
155 RT signal activated condition 0, 10 1 0 134
156 Stall prevention operation selection 0 to 31, 100, 101 1 0 134
157 OL signal waiting time 0 to 25 s, 9999 0.1 s 0 136
Sub functions
158 AM terminal function selection
1 to 3, 5 to 6, 8,
10 to 14, 17, 21
1186
Additional
function
$
160 User group read selection 0, 1, 10, 11, 9999 1 9999 137
162
Automatic restart after instantaneous
power failure selection
0, 1 1 0 89
163 First cushion time for restart 0 to 20 s 0.1 s 0 s 89
164 First cushion voltage for restart 0 to 100% 0.1% 0% 89
Automatic restart
after instantaneous
power failure
165 Restart stall prevention operation level 0 to 150% 0.1% 120% 89
168
Sub
functions
169
Parameters set by the manufacturer. Do not set.
170 Watt-hour meter clear 0

0 138
Initial
monitor
171 Actual operation hour meter clear 0

0 138
173 User group 1 registration 0 to 999 1 0 137
174 User group 1 deletion 0 to 999, 9999 1 0 137
175 User group 2 registration 0 to 999 1 0 137
User functions
176 User group 2 deletion 0 to 999, 9999 1 0 137
$
180 RL terminal function selection 1 0 138
$
181 RM terminal function selection 1 1 138
$
182 RH terminal function selection 1 2 138
$
183 RT terminal function selection 1 3 138
$
184 AU terminal function selection 1 4 138
$
185 JOG terminal function selection 1 5 138
$
186 CS terminal function selection
0 to 7, 10 to 14, 16,
9999
(24 Note 5)
1 6 138
$
190 RUN terminal function selection 1 0 140
$
191 SU terminal function selection 1 1 140
$
192 IPF terminal function selection 1 2 140
$
193 OL terminal function selection 1 3 140
$
194 FU terminal function selection 1 4 140
Terminal assignment functions
$
195 A, B, C terminal function selection
0 to 5, 8, 10, 11,
13 to 19, 25, 26,
98 to 105, 108,
110, 111, 113 to 116,
125, 126, 198, 199,
9999
(40 to 48 Note 5)
1 99 140
Additi-
onal
function
199 User's initial value setting 0 to 999, 9999 1 0 142
Parameter List
4
