Mitsubishi FR - S500 User Manual

21
Main circuit terminals
1
WIRING
1.2.11 Inverter-driven 400V class motor
In the PWM type inverter, a surge voltage attributable to wiring constants is generated
at the motor terminals. Especially for a 400V class motor, the surge voltage may
deteriorate the insulation. When the 400V class motor is driven by the inverter,
consider the following measures:
•Measures
It is recommended to take either of the following measures:
(1) Rectifying the motor insulation
For the 400V class motor, use an insulation-enhanced motor. Specifically
1) Specify the "400V class inverter-driven, insulation-enhanced motor".
2) For the dedicated motor such as the constant-torque motor and low-vibration
motor, use the "inverter-driven, dedicated motor".
(2) Suppressing the surge voltage on the inverter side
On the secondary side of the inverter, connect the optional surge voltage
suppression filter (FR-ASF-H).

Mitsubishi FR - S500 Specifications

General

Series	FR-S500
Protection Class	IP20
Control Method	V/f control
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short circuit
Communication Interfaces	RS-485 (Modbus RTU)
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Ambient Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m
Weight	Varies by model
