FX Series PLC User's Manual - Data Communication Edition
Non-Protocol Communication (RS/RS2 Instruction)
3 System Configuration and Selection
3.2 Applicable FX PLC and Communication Equipment
FX3G
(14-point, 24-point
type)
50 m
(164' 0")
500 m
(1640' 5")
FX
3G
(40-point, 60-point
type)
When using channel 1 (ch 1)
The communication equipment works as ch1 when connected to
the option connector 1.
50 m
(164' 0")
500 m
(1640' 5")
When using channel 2 (ch 2)
The communication equipment works as ch2 when connected to
the option connector 2.
50 m
(164' 0")
Ch2 is not available when the variable analog potentiometer
expansion board is connected to the option connector 2.
500 m
(1640' 5")
FX Series Communication equipment (option)
Total extension
distance
Check
FX 3G -485-BD
(European terminal block)
FX 3G -CNV-ADP FX 3U -485ADP(-MB)
(European terminal block)
ch1
FX
3G-485-BD
(European terminal block)
FX3G-CNV-ADP
ch1
FX
3U-485ADP(-MB)
(European terminal block)
ch2
FX
3G -485-BD
(European terminal block)
FX3U-ADP(-MB)
(Where  represents
232 and 485).
ch1 ch2
FX
3G -CNV-ADP
FX
3 U -485ADP(-MB)
(European terminal block)
