Mitsubishi HMA100V User Manual

8
Front panel, indoor module
How to use the front panel
All the most common settings are made from the panel such as
comfort etc. that you expect from the heat pump system to
full.
In order to make full use of it, certain basic settings must have
been made (see page 10) and the installation in general is carried
out according to the instructions.
Menu 1.0 (the temperature in the water heater) is
normally shown on the display.
The plus and minus buttons and the enter button are
used to scroll through the menu system as well as to
change the set value in some menus.
Menu types (Menu 8.1.1)
Control is classified into different menu types depending on
how “deep” into the controls you need to go.
■ Normal [N]: The settings you as a customer
often need.
■ Extended [U]: Shows all detailed menus except
the service menus.
Quick movement
To quickly return to the main menu from a sub menu, press
the following button:
Key lock
A key lock can be activated in the main menus by simultaneously
pressing the and the buttons. The key symbol will
then be shown on the display.
The same procedure is used to deactivate the key lock.
Language setting (Menu 8.1.2)
Language used in the display can be chosen in menu 8.1.2.
