2 - 17
SYSTEM CONFIGURATION2.
Temperature/
digital converter
module
A1S62RD3
For connecting to Pt100 (3-wire)
Temperature input, 2 channels
32
[32 special
points]
0.49 –
A1S62RD4
For connecting to Pt100 (4-wire)
Temperature input, 2 channels
32
[32 special
points]
0.39 –
A1S68TD Thermocouple input, 8 channels 32
[32 special
points]
0.32 –
Temperature
gcontrol module
A1S62TCTT-S2
Transistor output, thermocouple input
2 channels/module
PID control: ON/OFF pulse
32
[32 special
points]
0.19 –
A1S62TCTTBW-
S2
Transistor output, thermocouple input
2 channels/module
PID control: ON/OFF pulse, heater break
detection function
32
[32 special
points]
0.28 –
A1S62TCRT-S2
Transistor output, platinum RTD (Resistance
Temperature Detector) input
2 channels/module
PID control: ON/OFF pulse
32
[32 special
points]
0.19 –
A1S62TCRTBW-
S2
Transistor output, platinum RTD input
2 channels/module
PID control: ON/OFF pulse, heater break
detection function
32
[32 special
points]
0.28 –
A1S64TCTT-S1
Transistor output, thermocouple input
4 channels/module
PID control: ON/OFF pulse or 2 positioning
control
32
[32 special
points]
0.33 –
A1S64TCTTBW-
S1
Transistor output, thermocouple input
4 channels/module
PID control: ON/OFF pulse or 2 positioning
control
Heater break detection function
32
[32 special
points]
0.42 –
A1S64TCTRT
Transistor output,
thermocouple input, or platinum RTD input
[For standard control]
4 channels/module
PID control: ON/OFF pulse or 2 positioning
control
[For heating-cooling control]
2 channels/module
PID control: ON/OFF pulse
32
[32 special
points]
0.33
(0.19)*
–
*:When the
temperature
conversion
function of
unused channels
are not used in
the heating-cool
A1S64TCTRTBW
ing control
A1S64TCTRTBW
Transistor output,
thermocouple input, or platinum RTD input
[For standard control]
4channels/module
PID control: ON/OFF pulse or 2 positioning
control
[For heating-cooling control]
2 channels/module
PID control: ON/OFF pulse, wire breakage
detection
function
32
[32 special
points]
0.33
(0.19)*
–
Product Name Model Name Description
Number of occupied
points (points)
[I/O allocation
module type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
