2 - 18
SYSTEM CONFIGURATION2.
Temperature
gcontrol module
A1S64TCRT-S1
Transistor output, thermocouple input
4 channels/modules
PID control: ON/OFF pulse or 2 positioning
control
32
[32 special
points]
0.33 –
A1S64TCRTBW-
S1
Transistor output, thermocouple input
4 channels/modules
PID control: ON/OFF pulse or 2 positioning
control
Heater break detection function
32
[32 special
points]
0.42 –
Computer link
module
A1SJ71UC24-R2 Computer link function RS-232C, 1 channel 32
[32 special
points]
0.1 –
A1SJ71UC24-
PRF
Computer link function, printer function
RS-232C, 1 channel
32
[32 special
points]
0.1 –
A1SJ71UC24-R4
Computer link function, multidrop link function
RS-422/RS-485, 1 channel
32
[32 special
points]
0.1 –
Ethernet
interface module
A1SJ71E71N3-T 10 Base-T 32
[32 special
points]
0.69 –
Only AnACPU
equivalent device
range accessible
A1SJ71E71N-T 10 Base-T 32
[32 special
points]
0.56 –
A1SJ71E71N-B2 10 Base 2 (for Cheapernet) 32
[32 special
points]
0.66 –
A1SJ71E71N-B5 10 Base 5 (for Ethernet) 32
[32 special
points]
0.57 –
Intelligent
communication
module
A1SD51S
BASIC (interpreter/compiler)
RS-232C, 2 channel
RS-422/RS485, 1 channel
32
[32 special
points]
0.4 –
Product Name Model Name Description
Number of occupied
points (points)
[I/O allocation
module type]
Current
Consumption
Remark
5VDC(A) 24VDC(A)
