4 Conversion of the Projects
4.2 Precautions when Converting the Projects
47
4
*1 When the latch range of the device for keep of the FX3 Series is changed, the latch range must be changed.
*2 Set the parameter at [Parameter] →[FX5UCPU] → [CPU Parameter] → [Memory/Device Setting] → “Option Battery Setting” in [Device/
Label Memory Area Setting].
*3 Set the interrupt setting by the parameter accordingly.
*4 The parameter is reflected at [Parameter] → [FX5UCPU] → [Module Parameter] → [High Speed I/O] → [Input Function] → [General/
Interrupt/Pulse Catch]. Also, the parameter is reflected to [Module Parameter]→[Input Response Time].
*5 The parameter is reflected at [Parameter] → [FX5UCPU] → [CPU Parameter] → [Interrupt Settings] → [Fixed Interval Setting].
High-speed
counter
1-phase 1-count input C235 to C245 C235 to C245 Setting of the FX3 Series compatibility
assignment and replacement of the device
number are necessary by the parameter.
(Refer to Page 49 Precautions when
Using the High-speed Counters)
1-phase 2-count input C246 to C250 C246 to C250
2-phase 2-count input C251 to C255 C251 to C255
Contact CS235 to CS255 CS235 to CS255
Coil CC235 to CC255 CC235 to CC255
Current value CN235 to CN255 CN235 to CN255
Data register For general use D0 to D199 D0 to D199
For keep
*1
D200 to D7999 D200 to D7999
For special use D8000 to D8511 SD0 to SD8511 Refer to Page 48 SM/SD Device
Replacement.
File register File register
D1000 to D7999
Substitution is possible by using the
device initial value function.
Index register 16-bit Z device Z0 to Z7 Z0 to Z7
16-bit V device V0 to V7 Z10 to Z17
32-bit Z device (at
modification of direct value)
Z0 to Z7 Z0 to Z7 If necessary, replace the direct value
modification to the LZ device.
Extension register R0 to R32767 R0 to R32767 The battery mode setting is necessary.
*2
Extension file register ER0 to ER32767 Replaced to OUT SM4095
Pointer Normal pointer P0 to P4095 (except P63) P0 to P4095 (except P63)
END pointer P63 GOEND
Interrupt
pointer
*3
Input interrupt (delay
interrupt)
I00
I10
I20
I30
I40
I50
I0 to I15 Replaced as follows.
*4
I00→I0
I10→I1
I20→I2
I30→I3
I40→I4
I50→I5
=1: Rise interrupt
=0: Fall interrupt
When is 2 to 9, it will be replaced with
P4095.
Timer interrupt I6
I7
I8
I28 to I31 Replaced as follows.
*5
I6→I28
I7→I29
I8→I30
=1 to 99: Timer value
Counter interrupt I010
I020
I030
I040
I050
I060
I16 to I21 Replaced as follows.
I010→I16
I020→I17
I030→I18
I040→I19
I050→I20
I060→I21
Module access device Module number (0 to 7)
BFM number (0 to 32766)
Module number (0 to 15)
BFM number (0 to 65535)
The module number will be replaced
increasing by +2.
Decimal constant 16-bit: K-32,768 to K32,767
32-bit: K-2,147,483,648 to
K2,147,483,647
16-bit: K-32,768 to K32,767
32-bit: K-2,147,483,648 to
K2,147,483,647
Hexadecimal constant 16-Bit: H0 to HFFFF
32-Bit: H0 to HFFFFFFFF
16-Bit: H0 to HFFFF
32-Bit: H0 to HFFFFFFFF
Real constant -1.0×2
128
to -1.0×2
-126
, 0,
1.0×2
-126
to 1.0×2
128
-1.0×2
128
to -1.0×2
-126
, 0.
1.0×2
-126
to 1.0×2
128
Character string constant 32 single-byte characters 255 single-byte characters
Device name FX3U/FX3UC After replacing to
MELSEC iQ-F
