Front
Back
Air filter
4·5
Supplied with unit.
Set before use.
10
Front air intake
Do not block.
Handle
Raise handle to transport
00
Side air intakes (left/right)
Do not block.
Power plug
It is impossible to remove the back panel because
the two spots shown are fastened with two special
screws.
If the unit malfunctions, contact your Mitsubishi
dealer.
The water tank may contain water residue at time
of purchase. This is from final product testing at the
factory and is not due to a defect.
Names and Functions of Parts
Control panel
Pre-filter
Front panel
10
Water tank
11·1
Tank lid
11·1
Floating element
1
Front door
Louvre
1
Sensor
Do not cover.
Continuous drainage
outlet
NOTE
To Next Page
