4. STARTUP
4 - 23
(b) Fully closed loop control mode
Cumulative feedback
pulses
(Note)
Unit total power
consumption 2
(increment of 100 kWh)
Load-side encoder information 2
Load-side encoder cumulative
feedback pulses
Load-side encoder droop pulses
Load-side encoder information 1
(1 pulse unit)
Load-side encoder information 1
(100 pulses unit)
Load-side encoder information 2
Cumulative feedback pulses
Note. The displays in the frames are the standard control modes in one cycle with some
displays omitted.
To Next Page
