9 OUTLINE DRAWINGS
9 - 5
(d) MR-J4-200A(-RJ)
[Unit: mm]
6
6
6 78 6
168
6
156
45
90
85
Approx. 80
195
Cooling fan
air intake
Exhaust
161
Approx. 38.5
6
Approx. 21
Approx. 69.3
CNP2
CNP1
CNP3
φ
6 mounting hole
PE
With
MR-BAT6V1SET
Lock knob
Mass: 2.1 [kg]
Screw size: M4
Tightening torque: 1.2 [N•m]
L2
N-
P3
L11
L21
P4
L3
L1
C
D
P+
PE
Terminal
CNP1 CNP2
V
W
U
CNP3
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
Approx. 90
Approx. 6
3-M5 screw
78 ± 0.3
Approx. 6
Approx. 6
Mounting hole process drawing
Approx. 6
156 ± 0.5
Approx. 168
