11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 65
Dimensions [mm]
Servo amplifier
Power factor
improving DC
reactor
Dimensions
W W1 H D D1 D2 D3 d
Terminal
size
Mass
[kg]
Wire [mm
2
]
(Note)
MR-J4-60A4(-RJ) FR-HEL-H1.5K 66 50 100 80 74 54 37 M4 M3.5 1.0 2 (AWG 14)
MR-J4-100A4(-RJ) FR-HEL-H2.2K
Fig. 11.4
76 50 110 80 74 54 37 M4 M3.5 1.3 2 (AWG 14)
MR-J4-200A4(-RJ) FR-HEL-H3.7K 86 55 120 95 89 69 45 M4 M4 2.3 2 (AWG 14)
MR-J4-350A4(-RJ) FR-HEL-H7.5K Fig. 11.5 96 60 128 105 100 80 50 M5 M4 3.5 2 (AWG 14)
MR-J4-500A4(-RJ) FR-HEL-H11K 105 75 137 110 105 85 53 M5 M5 4.5 3.5 (AWG 12)
MR-J4-700A4(-RJ) 5.5 (AWG 10)
MR-J4-11KA4(-RJ)
FR-HEL-H15K 105 75 152 125 115 95 62 M5 M6 5.0
8 (AWG 8)
MR-J4-15KA4(-RJ) FR-HEL-H22K 133 90 178 120 95 75 53 M5 M6 6.0 8 (AWG 8)
MR-J4-22KA4(-RJ) FR-HEL-H30K
Fig. 11.6
133 90 178 120 100 80 56 M5 M6 6.5 14 (AWG 6)
Note. Selection conditions of wire size is as follows.
Wire type: 600 V grade heat-resistant polyvinyl chloride insulated wire (HIV wire)
Construction condition: Single wire set in midair
