11. OPTIONS AND AUXILIARY EQUIPMENT
11 - 67
Dimensions [mm]
Servo amplifier
Power factor
improving AC
reactor
Dimensions
W W1 H D (Note) D1 D2 d
Terminal
size
Mass
[kg]
MR-J4-10A(-RJ)
MR-J4-20A(-RJ)
FR-HAL-0.4K 104 84 99 72 51 40 M5 M4 0.6
MR-J4-40A(-RJ) FR-HAL-0.75K 104 84 99 74 56 44 M5 M4 0.8
MR-J4-60A(-RJ)
MR-J4-70A(-RJ)
FR-HAL-1.5K 104 84 99 77 61 50 M5 M4 1.1
MR-J4-100A(-RJ) FR-HAL-2.2K
115
(Note)
40 115 77 71 57 M6 M4 1.5
MR-J4-200A(-RJ) FR-HAL-3.7K
Fig. 11.7
115
(Note)
40 115 83 81 67 M6 M4 2.2
MR-J4-350A(-RJ) FR-HAL-7.5K 130 50 135 100 98 86 M6 M5 4.2
MR-J4-500A(-RJ) FR-HAL-11K 160 75 164 111 109 92 M6 M6 5.2
MR-J4-700A(-RJ) FR-HAL-15K 160 75 167 126 124 107 M6 M6 7.0
MR-J4-11KA(-RJ) FR-HAL-15K 160 75 167 126 124 107 M6 M6 7.0
MR-J4-15KA(-RJ) FR-HAL-22K
Fig. 11.8
185
(Note)
75 150 158 100 87 M6 M8 9.0
MR-J4-22KA(-RJ) FR-HAL-30K Fig. 11.9
185
(Note)
75 150 168 100 87 M6 M10 9.7
Note. Maximum dimensions. The dimension varies depending on the input/output lines.
