Mitsubishi MR-J4-70A User Manual

5. PARAMETERS
5 - 7
5.1.4 I/O setting parameters ([Pr. PD_ _ ])
Operation
mode
Control
mode
No. Symbol Name
Initial
value
Unit
Standard
Full.
Lin.
D.D.
P S
T
PD01 *DIA1 Input signal automatic on selection 1 0000h
PD02 For manufacturer setting 0000h
PD03 *DI1L Input device selection 1L 0202h
PD04 *DI1H Input device selection 1H 0002h
PD05 *DI2L Input device selection 2L 2100h
PD06 *DI2H Input device selection 2H 0021h
PD07 *DI3L Input device selection 3L 0704h
PD08 *DI3H Input device selection 3H 0007h
PD09 *DI4L Input device selection 4L 0805h
PD10 *DI4H Input device selection 4H 0008h
PD11 *DI5L Input device selection 5L 0303h
PD12 *DI5H Input device selection 5H 0003h
PD13 *DI6L Input device selection 6L 2006h
PD14 *DI6H Input device selection 6H 0020h
PD15 For manufacturer setting 0000h
PD16 0000h
PD17 *DI8L Input device selection 8L 0A0Ah
PD18 *DI8H Input device selection 8H 0000h
PD19 *DI9L Input device selection 9L 0B0Bh
PD20 *DI9H Input device selection 9H 0000h
PD21 *DI10L Input device selection 10L 2323h
PD22 *DI10H Input device selection 10H 0023h
PD23 *DO1 Output device selection 1 0004h
PD24 *DO2 Output device selection 2 000Ch
PD25 *DO3 Output device selection 3 0004h
PD26 *DO4 Output device selection 4 0007h
PD27 For manufacturer setting 0003h
PD28 *DO6 Output device selection 6 0002h
PD29 *DIF Input filter setting 0004h
PD30 *DOP1 Function selection D-1 0000h
PD31 For manufacturer setting 0000h
PD32 *DOP3 Function selection D-3 0000h
PD33 For manufacturer setting 0000h
PD34 DOP5 Function selection D-5 0000h
PD35 For manufacturer setting 0000h
PD36 0000h
PD37 0000h
PD38 0
PD39 0
PD40 0
PD41 0000h
PD42 0000h
PD43 0000h
PD44 0000h
PD45 0000h
PD46 0000h
PD47 0000h
PD48 0000h
