5. PARAMETERS
5 - 8
5.1.5 Extension setting 2 parameters ([Pr. PE_ _ ])
Operation
mode
Control
mode
No. Symbol Name
Initial
value
Unit
Standard
Full.
Lin.
D.D.
P S
T
PE01 *FCT1 Fully closed loop function selection 1 0000h
PE02 For manufacturer setting 0000h
PE03 *FCT2 Fully closed loop function selection 2 0003h
PE04 *FBN Fully closed loop control - Feedback pulse electronic gear 1 -
Numerator
1
PE05 *FBD Fully closed loop control - Feedback pulse electronic gear 1 -
Denominator
1
PE06 BC1 Fully closed loop control - Speed deviation error detection
level
400 [r/min]
PE07 BC2 Fully closed loop control - Position deviation error detection
level
100 [kpulse]
PE08 DUF Fully closed loop dual feedback filter 10 [rad/s]
PE09 For manufacturer setting 0000h
PE10 FCT3 Fully closed loop function selection 3 0000h
PE11 For manufacturer setting 0000h
PE12 0000h
PE13 0000h
PE14 0111h
PE15 20
PE16 0000h
PE17 0000h
PE18 0000h
PE19 0000h
PE20 0000h
PE21 0000h
PE22 0000h
PE23 0000h
PE24 0000h
PE25 0000h
PE26 0000h
PE27 0000h
PE28 0000h
PE29 0000h
PE30 0000h
PE31 0000h
PE32 0000h
PE33 0000h
PE34 *FBN2 Fully closed loop control - Feedback pulse electronic gear 2 -
Numerator
1
PE35 *FBD2 Fully closed loop control - Feedback pulse electronic gear 2 -
Denominator
1
PE36 For manufacturer setting 0.0
PE37 0.00
PE38 0.00
PE39 20
PE40 0000h
PE41 EOP3 Function selection E-3 0000h
