APPENDIX
App. - 5
Table: Recommended crimp terminals
Servo amplifier-side crimp terminals
Applicable tool
Symbol
Crimp terminal
(Note 2)
Body Head Dice
Manufacturer
a FVD5.5-4 YNT-1210S
b (Note 1) 8-4NS YHT-8S
c FVD2-4 YNT-1614
d FVD14-6 YF-1 YNE-38
DH-122
DH-112
e FVD5.5-6 YNT-1210S
f FVD22-6 YF-1 YNE-38
DH-123
DH-113
g FVD38-6 YF-1 YNE-38
DH-124
DH-114
h R60-8 YF-1 YET-60-1
TD-125
TD-113
i FVD5.5-8 YNT-1210S
j CB70-S8 YF-1 YET-150-1
TD-226
TD-213
JST
Note 1. Coat the crimping part with an insulation tube.
2. Some crimp terminals may not be mounted depending on the size. Make sure to use the
recommended ones or equivalent ones.
2) 400 V class
Wire [AWG] (Note 2)
Servo amplifier
L1/L2/L3
L11/L21 P+/C
U/V/W/
(Note 3)
MR-J4-60_4/MR-J4-100_4
MR-J4-200_4
MR-J4-350_4
14 14 14 14
MR-J4-500_4 (Note 1) 14: b 12: a
MR-J4-700_4 (Note 1) 12: a
14: b
10: a
MR-J4-11K_4 (Note 1) 10: d 14: b 14: e 8: f
MR-J4-15K_4 (Note 1) 8: f 12: d 6: c
MR-J4-22K_4 (Note 1) 6: g 12: h 4: i
Note 1. To connect these models to a terminal block, be sure to use the screws that come with the terminal block.
2. Alphabets in the table indicate crimping tools. Refer to the following table for the crimp terminals and crimping tools.
3. Select wire sizes depending on the rated output of the servo motors. The values in the table are sizes based on rated output of
the servo amplifiers.
Table: Recommended crimp terminals
Servo amplifier-side crimp terminals
Applicable tool
Symbol
Crimp terminal
(Note)
Body Head Dice
Manufacturer
a FVD5.5-4 YNT-1210S
b FVD2-4 YNT-1614
c FVD14-6 YF-1 YNE-38 DH-122/DH-112
d FVD5.5-6 YNT-1210S
e FVD2-6 YNT-1614
f FVD8-6 YF-1 YNE-38 DH-121/DH-111
g FVD14-8 YF-1 YNE-38 DH-122/DH-112
h FVD5.5-8 YNT-1210S
i FVD22-8 YF-1 YNE-38 DH-123/DH-113
JST
Note. Some crimp terminals may not be mounted depending on the size. Make sure to use the
recommended ones or equivalent ones.
