3. SIGNALS AND WIRING
3 - 29
Control
mode
Device Symbol
Connector
pin No.
Function and application
I/O
division
PST
Forward rotation
stroke end
LSP CN1-43 To start operation, turn on LSP and LSN. Turn it off to bring the motor to a
sudden stop and make it servo-locked.
Setting [Pr. PD30] to " _ _ _ 1" will enable a slow stop.
DI-1
LSN CN1-44 (Note) Input device Operation Reverse rotation
stroke end
LSP LSN
CCW
direction
CW
direction
1 1
0 1
1 0
0 0
Note. 0: Off
1: On
Set [Pr. PD01] as indicated below to switch on the signals (keep terminals
connected) automatically in the servo amplifier.
Status
[Pr. PD01]
LSP LSN
_ 4 _ _
Automatic
on
_ 8 _ _
Automatic
on
_ C _ _
Automatic
on
Automatic
on
When LSP or LSN turns off, [AL. 99 Stroke limit warning] occurs, and WNG
(Warning) turns on. When using WNG, enable it by the setting of [Pr.
PD23] to [Pr. PD28].
In the torque control mode, this device cannot be used during normal
operation. It can be used during the magnetic pole detection in the linear
servo motor control mode and the DD motor control mode. Also, when the
magnetic pole detection in the torque control mode is completed, this
signal will be disabled.
External torque
limit selection
TL CN1-18 Turning off TL will enable [Pr. PA11 Forward torque limit] and [Pr. PA12
Reverse torque limit], and turning on it will enable TLA (Analog torque
limit). For details, refer to section 3.6.1 (5).
DI-1
Internal torque
limit selection
TL1 To select [Pr. PC35 Internal torque limit 2], enable TL1 with [Pr. PD03] to
[Pr. PD22]. For details, refer to section 3.6.1 (5).
DI-1
Forward rotation
start
ST1 CN1-17 This is used to start the servo motor.
The following shows the directions.
DI-1
(Note) Input device
ST2 ST1
Servo motor starting direction
0 0 Stop (servo-lock)
0 1 CCW
1 0 CW
1 1 Stop (servo-lock)
Note. 0: Off
1: On
Reverse rotation
start
ST2 CN1-18 If both ST1 and ST2 are switched on or off during operation, the servo
motor will be decelerated to a stop according to the [Pr. PC02] setting and
servo-locked.
When " _ _ _1" is set in [Pr. PC23], the servo motor is not servo-locked
after deceleration to a stop.
To Next Page
